| ‧產品特色 |
2.4GHz/5GHz雙頻,支援802.11ax(Wi-Fi 6)無線技術,最新OFDMA+MU-MIMO和波束成型技術,AiMesh 技術,總體無線傳輸速度高達 1800Mbps,終身免費網路安全與進階家長控制功能,可完美搭配智慧住宅裝置包括 Alexa 技能和 IFTTT,單入介面:1*GbE RJ45(LAN/WAN),1*GbE RJ45(LAN),三年保固
NCC認證碼: CCAF20LP0790T3
BSMI認證碼: D33005
|
|
|
|
|
| 廠牌 |
ASUS華碩 |
| 產品型號 |
ZenWiFi AX Mini XD4 |
| 網路技術標準 |
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6 |
| 涵蓋範圍 |
大坪數 |
| 傳輸量 |
- 802.11a : 6,9,12,18,24,36,48,54 Mbps
- 802.11b : 1, 2, 5.5, 11 Mbps
- 802.11g : 6,9,12,18,24,36,48,54 Mbps
- 802.11n : up to 300 Mbps
- 802.11ac : up to 867 Mbps
- 802.11ax (2.4GHz) : up to 574 Mbps
- 802.11ax (5GHz) : up to 1201 Mbps
|
| 天線 |
內部 dual-band antenna x 2 |
| Transmit/Receive |
- MIMO technology
- 2.4 GHz 2 x 2
- 5 GHz 2 x 2
|
| 記憶體 |
256 MB Flash
256 MB RAM |
| Wi-Fi 技術 |
- OFDMA (Orthogonal Frequency Division Multiple Access)
- Beamforming: standard-based and universal
- 1024-QAM high data rate
- 20/40/80 MHz bandwidth
|
| 運作頻率 |
2.4 GHz / 5 GHz |
| 加密模式 |
WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , 支援 WPS |
| 管理程式 |
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log |
| VPN支援功能 |
- IPSec Pass-Through
- PPTP Pass-Through
- OpenVPN server
- PPTP client
- L2TP client
- OpenVPN client
|
| 連線類型 |
網路連線類型 : 浮動 IP, 固定 IP, PPPoE(支援 MPPE), PPTP, L2TP |
| 工具程式 |
Router setup wizard; Firmware restoration; Device discovery; printer setup utility |
| 網路埠規格 |
RJ45 for 1000 BaseT for WAN/LAN x 1, RJ45 for 1000 BaseT for LAN x 1 |
| 功能 |
- Router app
- MU-MIMO
- Airtime Fairness
- Smart Connect
- Traffic Analyzer
- Traditional QoS
- AiProtection Classic
- Parental Control
- Guest Network : 9
- VPN server : PPTP Server, OpenVPN Server, IPSec server
- VPN client : PPTP client, L2TP client, OpenVPN client
- IPTV support
- OFDMA
- Bandwidth Limiter
- Beamforming
|
| 按鈕 |
WPS Button, Reset Button |
| 電源規格 |
AC 輸入： 110V~240V(50~60Hz)
DC 輸出：12 V 最大1.5 A 電流 |
| 作業系統支援 |
- Windows® 10
- Windows® 8
- Windows® 7
- Mac OS X 10.6 or Above
- iOS9.0 (選購) or higher
- AndroidTM
|
| 產品尺寸 |
9.0 x 9.0 x 8.0 cm (寬x長x高)
XD4 Router NCC認證碼:CCAF20LP0790T3
XD4 Node NCC認證碼:CCAF20LP0800T6 |
| 包裝內容 |
- Router (XD4R)
- Node (XD4N)
- RJ45
- Adapter
- QSG
- Warranty Card
|
| Operation mode |
Wireless router mode
Access point mode |
| 備註 |
*Router(XD4R):1x Gigabit WAN/LAN port;1x Gigabit LAN Port; Weight: 295g; Wireless router mode.mesh mode.Access point mode
*Node(XD4N):1x Gigabit LAN Port; Weight: 290g; mesh mode
*Content may vary in different regions. |
| 保固 |
三年保固
※保固期有可能會變更或終止，恕不另行通知，以原廠公佈為準。
※以上規格資料或內附配件若有變更或任何錯誤，恕不另行通知，以原廠所公佈資料為準。 |
|
